| Type | Parameter |
| Model | BYD 0F4CBA3A 16S1P |
| Nominal voltage | 51.2V |
| Monomer capacity (1/3Cmin) | 135Ah |
| Rated energy | 7000Wh |
| Standard charging current | 20A @ 23°C |
| Max. continuous charge current | 170A @ 23°C |
| Charge cut-off voltage | 3.80V/Cell |
| Discharge cut-off voltage | 2.00V/Cell |
| Standard discharge current | 20A @ 23°C |
| Max. continuous discharge current | 100A @ 23°C |
| Max. charge power | 11600W（BOL/23°C/50%SOC/5S） |
| Max. discharge power | 11600W（BOL/23°C /50%SOC/5S） |
| Charge ambient temperature | -20~+50℃ |
| Discharge ambient temperature | -30~+55℃ |
| Short term storage ambient temperature | -20-+35℃（<3 months,20~60% SOC） |
| Long term storage ambient temperature | -20-+30℃（<1 year,30~60% SOC） |
| Storage humidity | 5%~95% |
| Overheating protection | 65℃ |
| Size | 1100*850*700/92.5mm |
| Weight | 47.5±0.05 Kg |
